Paslanmaz Boru

Özer Paslanmaz

Dış Çap (mm) 1.0 1.2 1.5 2.0 2.5 3.0 4.0 5.0 6.0
10 0.225 0.264 0.319
12 0.275 0.325 0.394 0.500
14 0.326 0.385 0.470 0.601
15 0,351 0.415 0.507 0.651
16 0.376 0.445 0.545 0.701
17.2 DN 10 3/8" 0.406 0.481 0.590 0.761 0.921
18 0.426 0.505 0.620 0.801
19 0.452 0.536 0.659 0.854
20 0.476 0.565 0.695 0.901
21.3 DN 15 1/2" 0.508 0.604 0.744 0.967 1.177
22 0.526 0.625 0.770 0.002
23 0.551 0.655 0.808 1.051
25 0.601 0.715 0.883 1.152 1.409
26.9 DN 20 3/4" 0.649 0.772 0.954 1.247 1.527 1.795
28 0.676 0.805 0.995 1.302 1.596 1.878
30 0.726 0.865 1.070 1.402 1.722 2.028
32 0.776 0.925 1.146 1.502 1.847 2.178
33.7 DN25 1" 0.819 0.977 1.209 1.588 1.953 2.306
35 0.851 1.016 1.258 1.653 2.035 2.404
38 0.929 1.109 1.375 1.808 2.229 2.637
40 0.977 1.166 1.446 1.903 2.348 2.779
42.4 DN32 1" 1/4 1.307 1.238 1.536 2.032 2.498 2.960 3.847
45 1.102 1.316 1.634 2.153 2.661 3.155
48,3 DN40 1" 1/2 1.184 1.415 1.758 2.319 2.867 3.403 4.438
50 1.227 1.466 1.822 2.404 2.974 3.531 4.607
50.8 1.247 1.490 1.852 2.444   3.591
51 1.252 1.496 1.859 2.454 3.036 3.606
52 1.277 1.526 1.897 2.504 3.099 3.681
54 1.327 1.587 1.972 2.604 3.224 3.831
57     2.085 2.754 3.412 4.057 5.309
60.3 DN50 2" 1.485 1.776 2.209 2.920 3.618 4.304 5.640
63.5 1.565   2.329 3.080 3.819 4.545 5.960
70 1.728 2.067 2.573 3.405 4.226 5.033 6.611
76.1 DN65 2" 1/2 1.881 2.251 2.802 3.711 4.607 5.491 7.222
80 1.978 2.368 2.948 3.906 4.852 5.784 7.613
84       4.107
88.9 DN80 3"     3.283 4.352 5.409 6.453 8.504
101.6 3" 1/2     3.760 4.988 6.204 7.407 9.776 12.094 14.363
104     3.850 5.108 6.354 7.587 10.016 12.395 14.724
114.3 DN100 4"     4.237 5.624 6.999 8.361 11.048 13.984 16.271
129 4 1 1/2     4.789 6.360 7.919 9.465 12.520 15.525 18.480
139.7 DN125 5"     5.191 6.896 8.589 10.269 13.592 16.864 20.087
154     5.728 7.612 9.484 11.343 15.024 18.655 22.236
168.3 DN150 6"     6.245 8.328 10.379 10.417 16.456 20.445 24.384
219.1 DN200 8"       10.870 13.560 16.230 21.540 26.810 32.020
237.0 DN250 10"       13.570 16.930 20.280 26.940 33.550 40.110
Firmamız Paslanmaz Sac, Paslanmaz Boru, Paslanmaz Kutu Profil, Paslanmaz Dikdirtgen Profil, Paslanmaz Çubuk, Paslanmaz Lama, Paslanmaz Çelik Köşebent, Paslanmaz Kare, Paslanmaz Altıköşe, Fiting Malzemeler yelpazesinde sizin değerli ihtiyaçlarınıza cevap verebilmektedir.
